Información Básica.
No. de Modelo.
m12-m80
personalización
según el dibujo o las muestras
tiempo de entrega
15 día
revestimiento
ptfe
certificado
ISO9001-2015, ISO45001-2018,ISO14001-2015
mercado
Glabol
Paquete de Transporte
Box
Especificación
m6-m80
Marca Comercial
DB
Origen
China
Código del HS
731816
Capacidad de Producción
5000ton/Year
Descripción de Producto
Esta especificación cubre una variedad de tuercas de carbono, aleación y acero inoxidable martensítico en el rango de tamaños de 1⁄4 a 4 pulg. Y métricas de M6 a M100 nominales. También cubre las tuercas austeníticas de acero inoxidable en el rango de tamaños 1⁄4 pulg. Estas tuercas están diseñadas para servicio a alta presión o alta temperatura, o ambas
Dimensiones para tuercas hexagonales pesadas(ASME/ANSI B18,2.2)
![Grade 8 304 Heavy Hex Nut ASTM A194](//img6.grofrom.com/www.yuxitoolsupply.es/226f3j00oOQkbwmtSFqH/Grade-8-304-Heavy-Hex-Nut-ASTM-A194.webp)
![Grade 8 304 Heavy Hex Nut ASTM A194](//img6.grofrom.com/www.yuxitoolsupply.es/226f3j00pFRoivfmSwcS/Grade-8-304-Heavy-Hex-Nut-ASTM-A194.webp)
![Grade 8 304 Heavy Hex Nut ASTM A194](//img6.grofrom.com/www.yuxitoolsupply.es/226f3j00gFGoVNYrrwkZ/Grade-8-304-Heavy-Hex-Nut-ASTM-A194.webp)
![Grade 8 304 Heavy Hex Nut ASTM A194](//img6.grofrom.com/www.yuxitoolsupply.es/226f3j00LyfoVtUqnJcZ/Grade-8-304-Heavy-Hex-Nut-ASTM-A194.webp)
![Grade 8 304 Heavy Hex Nut ASTM A194](//img6.grofrom.com/www.yuxitoolsupply.es/226f3j00INfqiuYnLdos/Grade-8-304-Heavy-Hex-Nut-ASTM-A194.webp)
![Grade 8 304 Heavy Hex Nut ASTM A194](//img6.grofrom.com/www.yuxitoolsupply.es/226f3j00LyYoVWGMLAbS/Grade-8-304-Heavy-Hex-Nut-ASTM-A194.webp)
![Grade 8 304 Heavy Hex Nut ASTM A194](//img6.grofrom.com/www.yuxitoolsupply.es/226f3j00DnGoWvYJyAcj/Grade-8-304-Heavy-Hex-Nut-ASTM-A194.webp)
![Grade 8 304 Heavy Hex Nut ASTM A194](http://img6.grofrom.com/www.yuxitoolsupply.es/226f3j00yNYkOqMjGFca/Grade-8-304-Heavy-Hex-Nut-ASTM-A194.webp)
Dimensiones para tuercas hexagonales pesadas(ASME/ANSI B18,2.2)
Diámetro | Anchura a lo largo de los pisos F | Grosor H | Anchura a lo largo de las esquinas G | |||||
No | máx | mín | No | máx | mín | máx | mín | |
1/4 | 1/2 | 0,500 | 0,488 | 15/64 | 0,250 | 0,218 | 0,577 | 0,556 |
5/16 | 9/16 | 0,562 | 0,546 | 19/64 | 0,314 | 0,280 | 0,650 | 0,622 |
3/8 | 11/16 | 0,688 | 0,669 | 23/64 | 0,377 | 0,341 | 0,794 | 0,762 |
7/16 | 3/4 | 0,750 | 0,728 | 27/64 | 0,441 | 0,403 | 0,866 | 0,768 |
1/2 | 7/8 | 0,875 | 0,850 | 31/64 | 0,504 | 0,464 | 1,010 | 0,969 |
9/16 | 15/16 | 0,938 | 0,909 | 35/64 | 0,568 | 0,526 | 1,083 | 1,037 |
5/8 | 1 1/16 | 1,062 | 1,031 | 39/64 | 0,631 | 0,587 | 1,227 | 1,175 |
3/4 | 1 1/4 | 1,250 | 1,213 | 47/64 | 0,758 | 0,710 | 1,443 | 1,382 |
7/8 | 1 7/16 | 1,438 | 1,394 | 55/64 | 0,885 | 0,833 | 1,660 | 1,589 |
1 | 1 5/8 | 1,625 | 1,575 | 35/64 | 0,575 | 0,519 | 1,876 | 1,796 |
1 1/8 | 1 13/16 | 1,812 | 1,756 | 1 7/64 | 1,139 | 1,079 | 2,093 | 2,002 |
1 1/4 | 2 | 2,000 | 1,938 | 1 7/32 | 1,251 | 1,187 | 2,309 | 2,209 |
1 3/8 | 2 3/16 | 2,188 | 2,119 | 1 11/32 | 1,378 | 1,310 | 2,526 | 2,416 |
1 1/2 | 2 3/8 | 2,375 | 2,300 | 1 15/32 | 1,505 | 1,433 | 2,742 | 2,622 |
1 5/8 | 2 9/16 | 2,562 | 2,481 | 1 19/32 | 1,632 | 1,556 | 2,959 | 2,828 |
1 3/4 | 2 3/4 | 2,750 | 2,663 | 1 23/32 | 1,759 | 1,679 | 3,175 | 3,035 |
1 7/8 | 2 15/16 | 2,938 | 2,844 | 1 27/32 | 1,886 | 1,802 | 3,392 | 3,242 |
2 | 3 1/8 | 3,125 | 3,025 | 1 31/32 | 2,013 | 1,925 | 3,608 | 3,449 |
2 1/4 | 3 1/2 | 3,500 | 3,388 | 2 13/64 | 2,251 | 2,155 | 4,041 | 3,862 |
2 1/2 | 3 7/8 | 3,875 | 3,750 | 2 29/64 | 2,505 | 2,401 | 4,474 | 4,275 |
2 3/4 | 4 1/4 | 4,250 | 4,113 | 2 45/64 | 2,759 | 2,647 | 4,907 | 4,688 |
3 | 4 5/8 | 4,625 | 4,475 | 2 61/64 | 3,013 | 2,893 | 5,340 | 5,102 |
3 1/4 | 5 | 5,000 | 4,838 | 3 3/16 | 3,252 | 3,124 | 5,774 | 5,515 |
3 1/2 | 5 3/8 | 5,375 | 5,200 | 3 7/16 | 3,506 | 3,370 | 6,207 | 5,928 |
3 3/4 | 5 3/4 | 5,750 | 5,563 | 3 11/16 | 3,760 | 3,616 | 6,640 | 6,341 |
4 | 6 1/8 | 6,125 | 5,925 | 3 15/16 | 4,014 | 3,862 | 7,073 | 6,755 |
